Barmesa® BCSF1½-8-5-2

Name: END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 5 HP, 3 PHASE, 3450 RPM, TEFC ENCLOSURE (BRM-BCSF1-1/2-8-5-2-@)
Brand: Barmesa®
SKU: BRM-BCSF1-1/2-8-5-2
Price: 5643.64 USD
Availability: InStock

1-1/2" Flange Stainless Steel Centrifugal Pump, 2" Suction, 5 hp @ 3500 rpm, 208-230/460V - 3P, TEFC Motor Enclosure (8" Impeller)

$5,643.64

BIPN:: BRM-BCSF1-1/2-8-5-2
Availability:: Typically Ships 7 - 21 days
Quantity Interval:: 1 / EA - Each

This product is NON-RETURNABLE.

Type Heavy-Duty Industrial
Series BCSF
Motor Type Electric Motor
Motor Connection Type Close-Coupled
Inlet Size 2 in FNPT Flange
Outlet Size 1-1/2 in Flange
Liquid Temperature Rating 250 deg F (max)
Pressure Rating 130 psi (max)
Pump Casing Material AISI 316 Stainless Steel
Impeller Type Closed
Impeller Diameter 8 in
Impeller Material AISI 316 Stainless Steel
Seal Type Single Mechanical
Seal Material Carbon/Silicon-Carbide, Viton
Hardware Material AISI 304 Stainless Steel
Horsepower 5 hp @ 3500 rpm
Voltage Rating 208-230/460V - 3P - 60 Hz
Motor Enclosure Type TEFC
Dimensions 20 in L x 15 in W x 12 in H

Data Sheet

Owner's Manual

END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 5 HP, 3 PHASE, 3450 RPM, TEFC ENCLOSURE (BRM-BCSF1-1/2-6-5-2-@)

1-1/2" Flange Stainless Steel Centrifugal Pump, 2" Suction, 5 hp @ 3500 rpm, 208-230/460V - 3P, TEFC Motor Enclosure (6" Impeller)

$4,764.70

BIPN: BRM-BCSF1-1/2-6-5-2 Availability: Typically Ships 7 - 21 days Quantity Interval: 1 / EA - Each

END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 3 HP, 3 PHASE, 3450 RPM, TEFC ENCLOSURE (BRM-BCSF1-1/2-3-2-@)

1-1/2" Flange Stainless Steel Centrifugal Pump, 2" Suction, 3 hp @ 3500 rpm, 208-230/460V - 3P, TEFC Motor Enclosure (6" Impeller)

$4,540.72

BIPN: BRM-BCSF1-1/2-3-2 Availability: Typically Ships 7 - 21 days Quantity Interval: 1 / EA - Each

END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 10 HP, 3 PHASE, 3450 RPM, TEFC ENCLOSURE (BRM-BCSF1-1/2-10-2-@)

1-1/2" Flange Stainless Steel Centrifugal Pump, 2" Suction, 10 hp @ 3500 rpm, 208-230/460V - 3P, TEFC Motor Enclosure (8" Impeller)

$6,464.46

BIPN: BRM-BCSF1-1/2-10-2 Availability: Typically Ships 7 - 21 days Quantity Interval: 1 / EA - Each

END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 7.5 HP, 3 PHASE, 3450 RPM, TEFC ENCLOSURE (BRM-BCSF1-1/2-7.5-2-@)

1-1/2" Flange Stainless Steel Centrifugal Pump, 2" Suction, 7.5 hp @ 3500 rpm, 208-230/460V - 3P, TEFC Motor Enclosure (8" Impeller)

$5,776.90

BIPN: BRM-BCSF1-1/2-7.5-2 Availability: Typically Ships 7 - 21 days Quantity Interval: 1 / EA - Each

END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 20 HP, 3 PHASE, 3450 RPM, TEFC ENCLOSURE (BRM-BCSF1-1/2-20-2-@)

1-1/2" Flange Stainless Steel Centrifugal Pump, 2" Suction, 20 hp @ 3500 rpm, 208-230/460V - 3P, TEFC Motor Enclosure (8" Impeller)

$8,575.33

BIPN: BRM-BCSF1-1/2-20-2 Availability: Typically Ships 7 - 21 days Quantity Interval: 1 / EA - Each

END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 15 HP, 3 PHASE, 3450 RPM, TEFC ENCLOSURE (BRM-BCSF1-1/2-15-2-@)

1-1/2" Flange Stainless Steel Centrifugal Pump, 2" Suction, 15 hp @ 3500 rpm, 208-230/460V - 3P, TEFC Motor Enclosure (8" Impeller)

$8,273.38

BIPN: BRM-BCSF1-1/2-15-2 Availability: Typically Ships 7 - 21 days Quantity Interval: 1 / EA - Each

END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 5 HP, 3 PHASE, 3450 RPM, TEFC ENCLOSURE (BRM-BCSF2-5-2-@)

2" Flange Stainless Steel Centrifugal Pump, 3" Suction, 5 hp @ 3500 rpm, 208-230/460V - 3P, TEFC Motor Enclosure

$6,144.07

BIPN: BRM-BCSF2-5-2 Availability: Typically Ships 7 - 21 days Quantity Interval: 1 / EA - Each

END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 1 HP, 3 PHASE, 1750 RPM, TEFC ENCLOSURE (BRM-BCSF1-1/2-8-@)

1-1/2" Flange Stainless Steel Centrifugal Pump, 2" Suction, 1 hp @ 1750 rpm, 208-230/460V - 3P, TEFC Motor Enclosure (8" Impeller)

$5,629.47

BIPN: BRM-BCSF1-1/2-8 Availability: Typically Ships 7 - 21 days Quantity Interval: 1 / EA - Each

END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 2 HP, 3 PHASE, 1750 RPM, TEFC ENCLOSURE (BRM-BCSF1-1/2-2-4-@)

1-1/2" Flange Stainless Steel Centrifugal Pump, 2" Suction, 2 hp @ 1750 rpm, 208-230/460V - 3P, TEFC Motor Enclosure (8" Impeller)

$5,803.84

BIPN: BRM-BCSF1-1/2-2-4 Availability: Typically Ships 7 - 21 days Quantity Interval: 1 / EA - Each

Barmesa® BCSF1½-8-5-2
