Barmesa® BCSF2-7.5-2

Name: END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 7.5 HP, 3 PHASE, 3450 RPM, TEFC ENCLOSURE (BRM-BCSF2-7.5-2-@)
Brand: Barmesa®
SKU: BRM-BCSF2-7.5-2
Price: 6277.33 USD
Availability: InStock

2" Flange Stainless Steel Centrifugal Pump, 3" Suction, 7.5 hp @ 3500 rpm, 208-230/460V - 3P, TEFC Motor Enclosure

$6,277.33

BIPN:: BRM-BCSF2-7.5-2
Availability:: Typically Ships 7 - 21 days
Quantity Interval:: 1 / EA - Each

This product is NON-RETURNABLE.

Type Heavy-Duty Industrial
Series BCSF
Motor Type Electric Motor
Motor Connection Type Close-Coupled
Inlet Size 3 in FNPT Flange
Outlet Size 2 in Flange
Liquid Temperature Rating 250 deg F (max)
Pressure Rating 130 psi (max)
Pump Casing Material AISI 316 Stainless Steel
Impeller Type Closed
Impeller Material AISI 316 Stainless Steel
Seal Type Single Mechanical
Seal Material Carbon/Silicon-Carbide, Viton
Hardware Material AISI 304 Stainless Steel
Horsepower 7.5 hp @ 3500 rpm
Voltage Rating 208-230/460V - 3P - 60 Hz
Motor Enclosure Type TEFC
Dimensions 22 in L x 17 in W x 12 in H

Data Sheet

Owner's Manual

END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 3 HP, 3 PHASE, 3450 RPM, TEFC ENCLOSURE (BRM-BCSF2-3-2-@)

2" Flange Stainless Steel Centrifugal Pump, 3" Suction, 3 hp @ 3500 rpm, 208-230/460V - 3P, TEFC Motor Enclosure

$6,077.44

BIPN: BRM-BCSF2-3-2 Availability: Typically Ships 7 - 21 days Quantity Interval: 1 / EA - Each

END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 15 HP, 3 PHASE, 3450 RPM, TEFC ENCLOSURE (BRM-BCSF2-15-2-@)

2" Flange Stainless Steel Centrifugal Pump, 3" Suction, 15 hp @ 3500 rpm, 208-230/460V - 3P, TEFC Motor Enclosure

$7,479.49

BIPN: BRM-BCSF2-15-2 Availability: Typically Ships 7 - 21 days Quantity Interval: 1 / EA - Each

END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 7.5 HP, 3 PHASE, 3450 RPM, TEFC ENCLOSURE (BRM-BCSF1-1/2-7.5-2-@)

1-1/2" Flange Stainless Steel Centrifugal Pump, 2" Suction, 7.5 hp @ 3500 rpm, 208-230/460V - 3P, TEFC Motor Enclosure (8" Impeller)

$5,776.90

BIPN: BRM-BCSF1-1/2-7.5-2 Availability: Typically Ships 7 - 21 days Quantity Interval: 1 / EA - Each

END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 10 HP, 3 PHASE, 3450 RPM, TEFC ENCLOSURE (BRM-BCSF2-10-2-@)

2" Flange Stainless Steel Centrifugal Pump, 3" Suction, 10 hp @ 3500 rpm, 208-230/460V - 3P, TEFC Motor Enclosure

$6,966.31

BIPN: BRM-BCSF2-10-2 Availability: Typically Ships 7 - 21 days Quantity Interval: 1 / EA - Each

END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 5 HP, 3 PHASE, 3450 RPM, TEFC ENCLOSURE (BRM-BCSF2-5-2-@)

2" Flange Stainless Steel Centrifugal Pump, 3" Suction, 5 hp @ 3500 rpm, 208-230/460V - 3P, TEFC Motor Enclosure

$6,144.07

BIPN: BRM-BCSF2-5-2 Availability: Typically Ships 7 - 21 days Quantity Interval: 1 / EA - Each

END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 20 HP, 3 PHASE, 3450 RPM, TEFC ENCLOSURE (BRM-BCSF2-20-2-@)

2" Flange Stainless Steel Centrifugal Pump, 3" Suction, 20 hp @ 3500 rpm, 208-230/460V - 3P, TEFC Motor Enclosure

$8,254.95

BIPN: BRM-BCSF2-20-2 Availability: Typically Ships 7 - 21 days Quantity Interval: 1 / EA - Each

END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED 7.5 HP, 3 PHASE, 3500 RPM, TEFC ENCLOSURE (BRM-IA1-7.5-2-@)

1" NPT Centrifugal Pump, 1-1/2" Suction, 7.5 hp @ 3500 rpm, 3-Phase, Cast Iron, TEFC (IE3) Motor Enclosure

$2,383.36

BIPN: BRM-IA1-7.5-2 Availability: Typically Ships 7 - 21 days Quantity Interval: 1 / EA - Each

END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 2 HP, 3 PHASE, 1750 RPM, TEFC ENCLOSURE (BRM-BCSF2-2-4-@)

2" Flange Stainless Steel Centrifugal Pump, 3" Suction, 2 hp @ 1750 rpm, 208-230/460V - 3P, TEFC Motor Enclosure

$6,311.36

BIPN: BRM-BCSF2-2-4 Availability: Typically Ships 7 - 21 days Quantity Interval: 1 / EA - Each

END-SUCTION CENTRIFUGAL PUMP CLOSE-COUPLED SS 3 HP, 3 PHASE, 1750 RPM, TEFC ENCLOSURE (BRM-BCSF2-3-4-@)

2" Flange Stainless Steel Centrifugal Pump, 3" Suction, 3 hp @ 1750 rpm, 208-230/460V - 3P, TEFC Motor Enclosure

$6,525.42

BIPN: BRM-BCSF2-3-4 Availability: Typically Ships 7 - 21 days Quantity Interval: 1 / EA - Each
