WIKA® 9767037

WIKA® Bourdon Tube Pressure Gauge, Glycerin Filled, Series 213.53, 15 psi, 1/4 in NPT Lower Connection, 2-1/2 in Dial Diameter, +/-2-1/2% Accuracy, 140 deg F, 304 Stainless Steel, 2.69 in Dia

WIKA® type 21X.53 gauges feature a stainless steel case for protection in harsh environments. The O-ring seal around the connection makes this gauge field liquid fillable. When filled, the 213.53 is excellent for high vibration and pulsation applications.

• Type Glycerin Filled
• Series 213.53
• Pressure Range 15 psi
• Connection Size 1/4 in NPT Lower
• Dial Diameter 2-1/2 in
• Accuracy +/-2-1/2 %
• Temperature Rating 140 deg F
• Material 304 Stainless Steel
• Dimensions 2.69 in Dia

• Vibration and shock resistant (with liquid filling)
• Pressure ranges up to 15000 psi (1000 bar)
• Intended for adverse service conditions where pulsating or vibration exists (with liquid filling)
• Suitable for gaseous or liquid media that will not obstruct the pressure system
• Additional error when temperature changes from reference temperature of 68 deg F (20 deg C) 0.4% of span for every 18 deg F (10 deg K) rising or falling temperature error
• Weather tight (NEMA 4X/IP 66)
• Copper alloy movement
• White ABS dial
• Black aluminum pointer
• Glycerin 99.7% type 213.53 case filling
• 304 stainless steel with vent plug and stainless steel crimp ring
• 2-1/2 in (63 mm) Less than and equal to 870 psi (60 bar) C-shape copper alloy, 2-1/2 in (63 mm) > 870 psi (60 bar) helical copper alloy, 2-1/2 in (63 mm) > 6000 psi (400 bar) helical stainless steel bourdon tube
• Polycarbonate with Buna-N gasket window
