Union Butterfield® 1012485
1700M General Purpose Straight Flute Hand Tap, M10x1.5 Coarse Thread, 6H Fit, Bottoming Chamfer, 4 Flute, 2-15/16" OAL, Right Hand, HSS, Bright
- BIPN:
- UTD-1012485
- UPC:
- 698464036118
- Availability:
- Typically Ships in 1 to 7 Days
- Quantity Interval:
- 1 / EA - Each
-
Union Butterfield® Straight Flute Hand Tap, General Purpose, Series: 1700M, Measurement System: Metric, Coarse Thread Standard, M10x1.5 Thread, Bottoming Chamfer, 4 Flutes, HSS, Bright, Class of Fit: 6H, Right Hand Cutting Direction, 1-1/4 in Thread Length, 2-15/16 in Overall Length, 0.381 in Shank Diameter, Steel, Stainless Steel, Copper, Titanium, Nickel, Cast Iron, Aluminum Magnesium and Synthetic Materials Material Application, D6 Thread Limit
-
- Type General Purpose
- Series 1700M
- Measurement System Metric
- Thread Standard Coarse
- Thread Size M10x1.5
- Chamfer Type Bottoming
- Number of Flutes 4
- Material HSS
- Finish/Coating Bright
- Class of Fit 6H
- Cutting Direction Right Hand
- Thread Length 1-1/4 in
- Overall Length 2-15/16 in
- Shank Diameter 0.381 in
- Material Application Steel, Stainless Steel, Copper, Titanium, Nickel, Cast Iron, Aluminum Magnesium and Synthetic Materials
- Thread Limit D6
-
- The most versatile taps for hand use or machine tapping in a wide variety of materials in through or blind hole applications
- A medium alloyed high speed steel that has good machinability and good performance
- HSS exhibits hardness, toughness and wear resistance characteristics that make it attractive in a wide range of applications
