Union Butterfield® 6008663

Union Butterfield® Straight Flute Hand Tap, General Purpose, Series: 1700M, Measurement System: Metric, Coarse, M22x1.5, Bottoming Chamfer, 4 Flutes, HSS, Bright, Class of Fit: 6H, Right Hand Cutting, 2-7/32 in Thread Length, 4-11/16 in Overall Length, 0.697 in Shank Dia, Steel, Stainless Steel, Copper, Titanium, Nickel, Cast Iron, Aluminum Magnesium and Synthetic Materials Material Application, D6 Thread Limit

Application: For through or blind hole applications

• Chamfer Type Bottoming
• Class of Fit 6H
• Cutting Direction Right Hand
• Finish/Coating Bright
• Material HSS
• Material Application Steel, Stainless Steel, Copper, Titanium, Nickel, Cast Iron, Aluminum Magnesium and Synthetic Materials
• Measurement System Metric
• Number of Flutes 4
• Overall Length 4-11/16 in
• Series 1700M
• Shank Diameter 0.697 in
• Thread Length 2-7/32 in
• Thread Limit D6
• Thread Size M22x1.5
• Thread Standard Coarse
• Type General Purpose

• The most versatile taps for hand use or machine tapping in a wide variety of materials in through or blind hole applications
• A medium alloyed high speed steel that has good machinability and good performance
• HSS exhibits hardness, toughness and wear resistance characteristics that make it attractive in a wide range of applications
