Union Butterfield® 1010653

Union Butterfield® Straight Flute Hand Tap, General Purpose, Series: 1528, Measurement System: Imperial, UNF Thread Standard, #4-48 Thread, Taper Chamfer, 3 Flutes, HSS, Bright, Class of Fit: 2B/3B, Right Hand Cutting Direction, 9/16 in Thread Length, 1-7/8 in Overall Length, 0.141 in Shank Diameter, Steel, Stainless Steel, Copper, Titanium, Nickel, Cast Iron, Aluminum Magnesium and Synthetic Materials Material Application, H2 Thread Limit

• Type General Purpose
• Series 1528
• Measurement System Imperial
• Thread Standard UNF
• Thread Size #4-48
• Chamfer Type Taper
• Number of Flutes 3
• Material HSS
• Finish/Coating Bright
• Class of Fit 2B/3B
• Cutting Direction Right Hand
• Thread Length 9/16 in
• Overall Length 1-7/8 in
• Shank Diameter 0.141 in
• Material Application Steel, Stainless Steel, Copper, Titanium, Nickel, Cast Iron, Aluminum Magnesium and Synthetic Materials
• Thread Limit H2

• The most versatile taps for hand use or machine tapping in a wide variety of materials in through or blind hole applications
• A medium alloyed high speed steel that has good machinability and good performance
• HSS exhibits hardness, toughness and wear resistance characteristics that make it attractive in a wide range of applications
