Union Butterfield® 1012441

Union Butterfield® Straight Flute Hand Tap, General Purpose, Series: 1700M, Measurement System: Metric, Coarse Thread Standard, M4x0.7 Thread, Taper Chamfer, 4 Flutes, HSS, Bright, Class of Fit: 6H, Right Hand Cutting Direction, 3/4 in Thread Length, 2-1/8 in Overall Length, 0.168 in Shank Diameter, Steel, Stainless Steel, Copper, Titanium, Nickel, Cast Iron, Aluminum Magnesium and Synthetic Materials Material Application, D4 Thread Limit

• Type General Purpose
• Series 1700M
• Measurement System Metric
• Thread Standard Coarse
• Thread Size M4x0.7
• Chamfer Type Taper
• Number of Flutes 4
• Material HSS
• Finish/Coating Bright
• Class of Fit 6H
• Cutting Direction Right Hand
• Thread Length 3/4 in
• Overall Length 2-1/8 in
• Shank Diameter 0.168 in
• Material Application Steel, Stainless Steel, Copper, Titanium, Nickel, Cast Iron, Aluminum Magnesium and Synthetic Materials
• Thread Limit D4

• The most versatile taps for hand use or machine tapping in a wide variety of materials in through or blind hole applications
• A medium alloyed high speed steel that has good machinability and good performance
• HSS exhibits hardness, toughness and wear resistance characteristics that make it attractive in a wide range of applications
