Apollo™ 94ALF-204-01A

Apollo™ Apollo International™ Ball Valve, 2-Piece, Series: 94ALF-A, 3/4 in Nominal, Solder, 600 psi CWP, -20 to 366 deg F, Full Port, Media: Gas/Fuel/Water, Lever Actuator, Chrome Plated Brass Ball, 2-3/4 in Inlet to Outlet Length, 2.14 in Top to Inlet Center, Brass Body, Brass Stem and PTFE Seat Trim, PTFE Softgoods

The Apollo™ International® 94ALF-A Lead Free forged brass ball valves combine reliable operation with maximum economy. Now with multi-agency approvals, the 94ALF-A is ideal for gas, fuels, fire protection and general plumbing and HVAC applications including potable water. Valves are ANSI 3rd party Lead Free certified.

• Type 2-Piece
• Series 94ALF-A
• Nominal Size 3/4 in
• End Style Solder
• Pressure Rating 600 psi CWP
• Temperature Rating -20 to 366 deg F
• Port Type Full
• Media Gas/Fuel/Water
• Actuator Type Lever
• Ball Material Chrome Plated Brass
• Inlet to Outlet Length 2-3/4 in
• Top to Inlet Center 2.14 in
• Body Material Brass
• Trim Material Brass Stem and PTFE Seat
• Softgoods Material PTFE

• Blow-out proof stem
• Distinctive white Lead free handle grip and blue Lead free hang tag
• Adjustable stem packing nut
• Multiple agency approvals
• Lead free brass (DZR) retainer
• UNS C37700 brass gland nut
• Steel, plated (with PVC grip) handle
• Plated steel handle nut
• Lead free chrome plated brass ball
• Complies with Federal Public law 111-380, ANSI 3Rd Party approved and listed
• PTFE stem packing
