Hammond Valve 412000012

Hammond Valve Globe Valve, Series: IB412, 1/2 in Nominal, Thread, 1000 psi WOG, Handwheel Actuator, 2.44 in Inlet to Outlet Length, 4-1/2 in Top to Inlet Center, Bronze Body, Bronze Trim, Graphite Packing, 2-1/2 in Hand Wheel

• Series IB412
• Nominal Size 1/2 in
• End Style Thread
• Pressure Rating 1000 psi WOG
• Actuator Type Handwheel
• Inlet to Outlet Length 2.44 in
• Top to Inlet Center 4-1/2 in
• Body Material Bronze
• Trim Material Bronze
• Softgoods Material Graphite Packing
• Hand Wheel Diameter 2-1/2 in

• 300 psi WSP
• 1000 psi WOG non-shock
• Bronze renewable disc
• Union bonnet
• Not intended for use in potable water
• Integral disc and stem
